Home Wuyi Colored Garden Tool Co., Ltd. EPA, EEC Approved Quad (QC-B403)
Specifications
| Prod Model: | QC-B403 |
|---|---|
| Certification: | CE |
| Displacement: | 110CC |
| Transmission Type: | Automatic |
| Engine Type: | 4 Stroke |
| Transmission System: | Chain Drive |
Product Description
Spide man1) Engine:Gasoline,4-stroke, 4 gear, 4speed
2) Displacement:50cc/70cc/110cc
3) Bore& stroke:34.0mmx41.5mm(50cc);
47.0mmx41.5mm(70cc);
52.3mmx50.0mm(110cc);
4) Stater:Electric and kick start
5) Battery:12v/7Ah
6) Tank capacity:3.0L
7) Brakes:Front and rear hydraulic disk brakes
8) Wheel size(front/rear):2.15"x14"/4.5"x12"
9) Ground clearance:20mm
10) Load:300 lbs
11) Front fork + shock:780mm
12) Front shock:310mm
13) Front shock play:60mm
14) Rear central shock absorber:130mm
15) Seat hieght:515mm
16) G.W./N.W.:70KG/62KG
17) Body size:2150mm x 700mm x 970mm
18) Conveyance:20'ft:52pcs;40'ft:113pcs
40'hq:141pcs
