En15194 Electric Bicycle

Specifications

Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe

Product Description

MODEL: MINI
Main components
Tyre size: KENDA 20"x 1, 75 city style Frame: Aluminium alloy
Motor: 250W 24V last generation hub gear brushless motor Front fork: Aluminium alloy suspension, ZOOM brand
With Pedaling assistant system PAS / Throttle (if requested) Brakes: V-brake.
Battery: Lithium-ion 24V 10Ah, warranty 1 year; UL, CE certificated. Lights: Front and rear LED lights, management by display

Controller 3 speed: Low 13Km/h Med 20Km/h High 25Km/h (for EU) Gear set: Shimano 7 speed Megarange
Autonomy: 50-65Km(PAS) Crank: Front crank 48 teeth
Packing size: 148x26x74cm, carton 0, 9mm Spokes: Carbon steel and nipples in bronze.

Rims: Aluminium alloy, double wall, inner 19mm Bolts and nuts: Stainless steel
Pedals: Aluminium alloy, city style Chain: Silver color, KMC high quality chain
Net weight: 22 KG battery included, Max load: 120Kg Display: Battery indicator, management of the 3 speed, LED lights and PAS system
Gross weight: 27 KG
Mudguards: In aluminium alloy or black plastic. Container 20feet 96PCS; 40feetHQ 214PCS
