Home Suzhou Thriving Medical Equipment Corp. Electric Standing Power Wheelchair (THR-FP130)
Electric Standing Power Wheelchair (THR-FP130)
| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
| Prod Model: | THR-FP130 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Model No: | Thr-Fp130 |
| Using Site: | Full Body |
| Using Ambient: | Indoor |
| Electric Wheelchair: | Standing and Lying Electric Wheelchair |
| Battery Weight: | 30 Kg |
| Max Speed: | 7 Km/H |
| Lying Time: | 15s |
| Total Weight: | 95 Kg |
| Power Supply: | Electric-Powered |
| Use As: | Electric Standing Power Wheelchair |
Product Description
Product Description
Electric wheelchair
-Standing wheelchair
-Standing, seat and lay down function
-Easy operate
-Your good helper in daily
THR-FP130 Electric Standing Power Wheelchair
Seat and Stand up function, with protect belts on the chest and legs;
It can be lay down at any position according to your need easily;
The arm rest is openable, for nursing staff to help user more easily.
With handle rails, for user to up and down seat, and also can put dining table over it.
The Head rest is adjustable freely upward and downward;
Wheels with Sway castors to confirm user's safe.
Handle controller, with speed indication and power indication.
Max speed | ≤7 km/h | Mileage | ≤30km |
| Total weight | 95 kg | Battery weight | 30 kg |
| Climbingangle | ≤15° | Brake distance | ≤1.5m |
| Parking angle | ≤15° | Obstacle height | ≤30mm |
| Stand time | 15s | Lying time | 15s |
| Groove width | ≤50mm | Work environment | -20C°~ 45C° |
| Battery | 4×20Ah | Rated voltage | 24V |
| Motor power | 2×250W | Motor voltage | DC24V |
| Charge input | AC220V50HZ ±15 | Charge output | DC28.8V |
| Charge output | 5A | Charge time | 10 hours |
| Static stability | Vertical 15° Lateral 10° | Dynamic Stability | Uphill 10° Downhill 8° Turing 5° |
| Max load | ≤100kg | Age | <5 years |
| Storage Environment | Packaged products should be stored in the vessel or indoor where the ambient temperature is -10°-50°and relative humidity is less than 90%. There are no corrosive liquids or gas, no strong mechanical vibration. The storage must be clean and has good ventilation | ||
