Specifications
Prod Model: |
JSE207 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wheel Hub: |
Lightweight Alloy Hubs |
Voltage Of Battery: |
48V |
Motor: |
Brushless |
Battery Type: |
Lead-acid Battery |
Frame Material: |
Steel |
Power: |
351-500W |
Maximum Loading Capacity: |
≥120kg |
Running Distance: |
45-60KM |
Charging Time: |
6-8h |
Certification: |
COC |
Wheel Size: |
16" |
Max Speed: |
20-40km/h |
Brake: |
HUB Brake For Front Wheel |
Product Description
SAFETY FEATURES INCLUDE:
1. Large headlight and tail light, turn signals
2. Horn with audible alarm while turning
3. Wide rear view mirrors
4. Heavy duty kickstand
5. CUL Listed Smart charger
6. Automotive type cushioned brake system
7. Back-lighted instrument panel for night time operation
8. Digital rear wheel and motor lock cannot be bypassed or deactivated without key
9. Scootalert TM Anti-theft Alarm System with remote control
10. Front Hydraulic suspension absorption shock and shock absorbing rear fork
Motor |
500-800 Watts High Power Brushless Hub Motor |
Batteries |
48 Volt 20 AH CE Sealed Lead Acid battery |
Max Speed |
32km/h(20 mph) |
Torque |
26 N. M., climbs up to 25º hill |
Range |
55-62 km depending on Riders Weight, Road Conditions Etc |
Load recommended |
125kgs |
Max Loading capacity |
150kgs |
Tires |
16" x 3.0 |
Rims |
Alluminum Alloy |
Mirrors |
Right and Left mirrors included |
Front Shocks |
Premium Dual Front Fork Shock Absorbers |
Rear Shocks |
Dual shock abosorbers for maximum comfort |
Brakes |
Front and rear drum brake |
Controller |
The brains of the vehicle interfaces the batteries and motor: 48 volt/ 25 Amp |
Dashboard |
Displays voltage, lighting, system staus, charging status on an easy to read display. |
Lights |
Headlight, Turn Signals, Rear Turn Signals, wheel reflectors |
Seat |
Comfort Motorcycle style |
Charger |
48 Volt DC Output, 110-240 Volt /50-60Hz AC Input intelligent Electronic |
Charging Time |
6-8 Hours Dependant on use! |
Weight of Scooter |
72kgs. (including 28kgs. Battery Pack) |
Kickstands |
Steel, black, with both double kickstand and single flickstand |
Pedals |
Pedals for meeting ebike legal requirements |
Size(L*W*H) |
1820x620x1100mm |
Assembly |
Pedals, Front tire, Front Fender (10 - 15 minutes) |
