Price: | US $ 1040/Piece |
---|---|
Trade Terms: | FOB,CIF,others |
Min Order: | 10/Piece |
Pay Type: | L/C,T/T |
Specifications
Prod Model: | D410A |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Eastern Asia,Western Europe |
Climbing Capacity: | 12 Degrees |
Running Distance: | <45KM |
Motor: | Brushless |
Max Speed: | <20km/h |
Battery Type: | Lead-acid Battery |
Frame Material: | Steel |
Voltage Of Battery: | 24V |
Certification: | EEC |
Maximum Loading Capacity: | ≥120kg |
Wheel Hub: | Alloy Hubs |
Folded: | Unfolded |
Charging Time: | >10h |
Part: | Motor |
Brake: | Front : Drum Rear : Drum |
Power: | 450W |
Wheel Size: | 10" |
Product Description
Product DescriptionOverall Dimentions (LXWXH) | 1400 x630x1230mm |
Max Forward Speed | 8.3km/h |
Max Backward Speed | 4.6km/h |
Braking Distance(≤) | 2m |
Max Climbing slope | 12degrees |
Ground Clearance | 135mm |
Loading Capacity | 120kg |
turning radius | 1.72m |
Range per Change | 40km |
Front Tire | 10" |
Rear Tire | 10" |
Motor Rated Power | 450w |
Controller | PG S-Drive 70A |
Charger | 24V 5A |
Battery | 2V/45AH x 2 |
Braking System | Electric Regenerative Braking |
N.W. | 107kg |
G.W. | 120kg |
Battery Weight(2pcs) | 29.7kg |
Packing Size: | 1480x680x860 mm |
Container packing | 20GP : 36units 40GP :75units 40HQ : 88units |
