EEC ATV / Quad (DP-200(EEC)-H)

Specifications

Prod Model:	DP-ATV200(EEC)-H

Product Description

200cc, EEC ATV (DP-200(EEC)-H)
1) ATV Engine type: single cylinder, air-cooling, 4-stroke
2) Power: 8.9kW/7,500rpm
3) Max. torque: 13.2Nm/6,500rpm
4) Min. ground clearance: 150mm
5) Wheel base: 1,110mm
6) Fuel tank capacity: 4L
7) Transmission mode: axis
8) Start mode: electric
9) Tires:
a) Front wheels: 19 x 7-8
b) Rear wheels: 18 x 9.50-8
10) Max. speed: ≥72km/h
11) Break type (F/R): drum/drum
12) Power source: 12V, 9Ah
13) Height of seats: 770mm
14) Dry weight: 150kg
15) Load capacity: 150kg
16) Climbing degree: ≥25 degree
17) Front hanging: double arm-swing
18) Rear hanging: integral
19) Cylinder size: 63.5 x 62.2mm
20) Displacement: 196.98mL
21) Transmission: 4 gears with reverse gear , manual clutch
22) Min. turning radius: 2,400mm
23) Parking trig: mechanical lock
24) Ignition mode: CDI
25) Engine oil: 1.1L
26) Gear oil: 0.2L
27) Max. number of riders: 1
28) Lubrication: press splash
29) Compression proportion: 9.2:1
30) Product Dimensions (L x W x H): 1,585 x 980 x 1,010mm

Carton dimensions: 1,490 x 840 x 770mm
Conveyance: 20'ft/29 units, 40'ft/ 64 units, 40HQ/66 units.
