Specifications
Prod Model: |
MS-04-06 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Certification: |
CE |
Folded: |
Folded |
Voltage: |
24V |
Load Capacity: |
100-200kg |
Climbing Capability: |
12?? |
Product Description
Weight capacity: 150kg
Rear wheel size: 4.10/3.50-6 13"
Front wheel size: 8"
Anti-tip wheel size: 75mm X 25mm
Battery: 12V / 38AH X 2
Charger: AC100-240V, 50/60Hz, OUTPUT: 24V-4A
Controller: PG
Motor: 24V / 320W X 2
Gross weight: 102kg
Net weight (with batteries): 93 kg
Net weight (without batteries): 72kg
Overall dimensions: 1150 X 630 X 1280 mm
Carton dimensions: 880 X 670 X 880mm
Seat dimension: 450 X 440 X 600mm
Battery dimension: 194x163x177mm
Range: 35km per battery charge
Incline capability: 12 degrees
Turning radius(min): 600mm
Recharge time: 6-8hr
Forward speed: 6-12km/h (adjustable)
Backward speed: 2.4-6km/h (adjustable)
Container loading: 60units/20'FCL, 120units/40'FCL, 142units/40'HQ
