Home Wiztem Industry Company Limited Direct Selling 200cc Mini Quad ATV
Direct Selling 200cc Mini Quad ATV
| Price: | US $ 1127.34-1281.08/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,D/P,Money Gram,Western Union |
| Prod Model: | 46AT2502-A1304 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Overall Size: | 2130 X 1200 X 1200mm |
| Wheel Number: | 3 |
| Piston Displacement: | 200cc |
| Fuel Tank: | 3.0 Liters |
| Fuel Type: | Unleaded Gasoline Above No.90 |
| Starting System: | Cdi Electric |
| Battery: | 12V.9ah |
| Drive Train: | Chain |
| Rating Power: | 11kw7500rpm |
| Max. Torque: | 18.5n.M/6000rpm |
| Transmission System: | Chain Drive |
| Transmission Type: | Automatic |
| Certification: | DOT |
| Engine Type: | 4 Stroke |
| Fuel: | Gas / Diesel |
| Displacement: | 200CC |
| Structure: | Without Door |
| Maximum Speed: | >75 km/h |
| Brake Type: | Disc Brake |
Product Description
ATVCE Approved 200CC Water Cooling Engine ATV with three wheels
AT2502-A
Key Specifications:
1. Overall size: 2130 x 1200 x 1200mm
2. Wheel number: 3
3. Piston displacement: 200cc
4. Fuel tank: 3.0 liters
5. Fuel type: Unleaded gasoline above No. 90
6. Engine type: Single cylinder, 4 stroke, water Cooling, Double Wishbones Suspension, manually operated clutch
7. Starting system: CDI electric
8. Battery: 12V. 9AH
9. Drive train: Chain
10. Rating power: 11kw7500rpm
11. Max. Torque: 18.5N. M/6000rpm
12. Brake(Front/Rear): Front Double disk brake/ Rear Single disc brake
13. Wheel size: Front: 235/30R12, rear: 235/30R14
14. Minimum ground clearance: 160mm
15. Max. Load: 100kg
16. Max. Speed: 80km/h,
17. Wheelbase: 1480mm
18. Electric spark plug: A7RTC
19. Exhaust pipe: Single/double
20. Wheel hub material: Iron/Aluminum
21. Shock absorption: Front the spring /Rear the spring
22. Seat height: 700mm
23. Compression ratio: 10: 1
24. Gearshift method: Stamped on the gear
25. Lubrication: Combined Pressure and Splashing
Package: Iron cage with carton outside
26. Net weight: 158kgs/348lbs
27. Gross weight: 180kgs/396lbs
28. Carton size: 2070x1220x850mm/1pc
29. Container: 12pcs/20', 32pcs/40'HQ
Special Features:
L Chain Driving power Transmission
L Powerful water cooling engine
L Before hand brake back foot on the brakes
Minimum Order Quantity: 1pc
