Specifications
Prod Model: |
yoyo |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Qty Container: |
105 Units/40hq |
Brand Name: |
Sinyo Wind/ OEM |
Wheel: |
3.5-10(F)3.5-10(R) |
Ground Clearance: |
110mm |
Dimension: |
1870.860.1160 |
Available Color: |
Red/Black/White |
Packing Size: |
1700 X 460 X 860 mm |
Max Speed: |
>50km/h |
Certification: |
COC |
Engine: |
4 Stroke |
Maximum Loading Capacity: |
75-120kg |
Fuel Tank Capacity: |
5-8L |
Folded: |
Unfolded |
Displacement: |
50cc-150cc |
Product Description
Wuxi Sinyo Wing Motorcycle Co., Ltd. is located in Wuxi, Jiangsu Province, specialized in motorcycles, scooters, tricycles,E-scooters and CKD products. Our company has professional facilities, technologies and inspectors who have been working in this field for long years and could share the correct advice with clients!
DIMENSIONS |
Displacement | 49.5ml |
Engine | Single Cylinder, 4 Stroke |
Bore & Stroke | 39×41.5 |
Cooling System | Air Cooled |
Compression Ratio | 10.5:1 |
Fuel feed | 90# |
Max Power( Kw/rpm) | 2.5/7500 |
Max Torque(N.M/rpm) | 2.8/5500 |
Max Speed | 50 kmph |
Fuel consumption | 2.0L/100KM |
Ignition | CDI |
Transmission | Belt |
Fuel tank capacity | 5 L |
Starting System | Electric+kick start |
Front Brakes | Disc brake |
Rear Brake | Drum brake |
Front suspension | Hydraulic Suspension |
Rear suspension | 1 Hydraulic Suspension |
Front wheels | steel 3.5-10 |
Rear wheels | steel 3.5-10 |
BASIC SPECIFICATION |
Ground clearance | 125 mm |
Wheel Base | 1240 mm |
Seat Height | 710 mm |
Payload | 75kg |
Net Weight | 75 kg |
Gross Weight | 98 kg |
Packing size | 1700 x 460 x 860 mm |
Our Services
1.We supply the whole set of spare parts of motorcycles, from Engines to Screws.
2.We guarantee 100% rate of qualified products in your factory.
3.Our engineers have more than 20 years experience in motorcycle production.
4.We guarantee 30 days of delivery time.
5.We guarantee that the vehicles for free service of 12 months or 12000 miles.
Company Information
Wuxi Sinyo Wing Motorcycle Co., Ltd. is located in Wuxi, Jiangsu Province, specialized in motorcycles, scooters, tricycles,E-scooters and CKD products. Our company has professional facilities, technologies and inspectors who have been working in this field for long years and could share the correct advice with clients!
