CUB / Motorcycle (CB125R)

Specifications

Prod Model:	CB125R

Product Description

Body Style:

Drive Line: Chain

Engine Family: Cub

Engine Displacement: 125cc

Horse Power:8.5hp@8500 rpm

Net Weight: 97 kg

Gross Weight: 105 kg

Dimensions:Length: 1910-710-1190(mm)

Ground Clearance: 125mm/85mm

Wheel Base: 1400mm

Engine Specification:

Type: 4-stroke, Air cooling, Single Cylinder

Manual or Automatic: Auto

Fuel: Gasoline

Displacement: 123.6ml

Bore-Stroke: 50mm-55.5mm

Max Power: 6.2 kw/8500 rpm

Max Torque: 8.0 N.m/8500 rpm

Compression Ratio: 9.00:1

Transmission:

Model: Automatic Single/Double Clutch

Type: 4 gears

Gearing N-1-2-3-4

Driving Configuration:

Type: Chain

Other Data:

Suspension: Telescopic, Damper Rear

Brakes: Fr Drum/Hydraulic Disc Brake, Rear Drum

Steering: Tubular, Plastic Covered

Wheel and Tires:13 inches/13 inches(Fr/Rr)

Headlight: Halogen Bulb(can be in Philips)

Start: Electric/Kick

Battery: 12V5A,Maintainience Type

Ordering Relative Data:

Loading Qty: Cbu-105 units/40HQ, Ckd-140 Set
