Specifications
Prod Model: |
HD250-12A |
Markets: |
North America,Western Europe |
Export Markets: Global: |
EEC/Coc Approval |
Type: |
Straddle |
Engine Type: |
4-Stroke |
Fuel: |
Gas / Diesel |
Certification: |
CQC |
Condition: |
New |
Displacement: |
125cc & 250cc |
Product Description
We are making Motorcycles, Scooters, US Style Chopper, Bajaj Passenger Tricycles, Cargo trikes, electric motorcycles, electric bikes, ebikes, electric scooter, Electric tricycles, ATV quad, spare parts, helmets etc .
Size(L×W×H) | 2235*840*1140 MM |
Wheelbase | 1460 MM |
Ground Cleareance | 110 MM |
Wheels Front/rear | Alloy |
Tyres Front | 90/90-18 MM |
Tyres Rear | 130/90-15 MM |
Brakes Front | Disc brake/right hand operation |
Brakes Rear | Drum brake/foot operation |
Dry Weight | 150 Kg |
Max. loading | 150 Kg |
brake distance | 40km/h 5M ≥ |
Min fuel | ≥2.7 KM |
maxinum speed | ≥120 KM |
Engine type | In line 2-cylinder,Oil-cooled, 4-stroke, |
Bore×Stroke | 70.0*65.0 M M |
Displacement | 250.1 ML |
Compression Ratio | 11:1 |
Carburation | Vacuum diaphragm |
rated power | kw( r/min)16.5/7500 |
Max. torque | N.m(r/min)21.5/6000 |
Ignition | C.D.I |
Starter | Electric start |
shift type | International |
Transmission type | Chain |
Clutch | Manual operation |
Gasoline | ≥ 93# |
Transmission Lubricant | W/ HQB-10 |
Lubricantion Oil capacity | 2.5 L |
Lubrication | Pressure Splash |
Spark plug | A7TC |
Battery type | 12V 9AH |
