China Made Cheap 50cc ATV (AT0501-A)
| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 5/Piece |
| Pay Type: | L/C,T/T,Paypal,Western Union |
Specifications
| Prod Model: | AT0501-A |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Wheel Number: | 4 |
| Product Size: | 1180X735X755mm |
| Compression Ratio: | 9.0:1 |
| Battery: | 12V 5ah |
| Fuel Tank Volume: | 3.4L |
| Oil Consumption: | 3.4L/100km |
| Lubricating Oil: | Se15W/40 Sf10W/30 |
| Load Capacity: | 85kgs |
| Rated Power: | 2.0kw/8000r/Min |
| Rated Torque: | 2.6n.M/5000r/Min |
| Transmission System: | Chain Drive |
| Transmission Type: | Automatic |
| Certification: | CE |
| Engine Type: | 4 Stroke |
| Fuel: | Gas / Diesel |
| Displacement: | 50CC |
| Structure: | Without Door |
| Maximum Speed: | 40km/H |
| Brake Type: | Front: Drum Brake; Rear: Disc Brake |
Product Description
China Made Cheap Gas-Powered 4-Stroke Full Automatic Engine 50CC ATVAT0501-A
Key Specifications:
1. Wheel number: 4
2. Product size: 1180x735x755mm
3. Compression ratio: 9.0: 1
4. Piston displacement: 50cc
5. Engine: Single-cylinder, 4-stroke, air-cooling
6. Battery: 12V 5AH
7. Fuel tank volume: 3.4L
8. Oil consumption: 3.4L/100km
9. Lubricating oil: SE15W/40 SF10W/30
10. Starting system: CDI electric start
11. Electric sparking plug: A7RTC
12. Drive system: Chain drive
13. Brake: Front: Drum brake; Rear: Disc brake
14. Max speed: 40km/h
15. Load capacity: 85kgs
16. Rated power: 2.0Kw/8000r/min
17. Rated torque: 2.6N. M/5000r/min
18. Wheel: Front and rear 145/70-6
19. Seat height: 67cm
20. Gearshift method: Automatically
21. Clutch method: Automatic clutch
22. Break method: Manual brake
23. Shock absorption method: Front and rear hydraulic shock absorber
24. Color available: Black, blue, silver, red optional
Package: Iron cage with carton outside
25. Net weight: 81kgs/178lbs
26. Gross weight: 97kgs/214lbs
27. Carton size: 115x69x59cm/1pc
28. Container: 54pcs/20', 124pcs/40', 136pcs/40'HQ
Special Features:
Remote starter
Emergency stop button ensures safety
Rotative gearing speed control
High quality
Minimum Order Quantity: 5pcs
