Specifications
Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
Engine Type: |
4-Stroke |
Certification: |
CQC |
Type: |
Racing Motorcycle |
Fuel: |
Gas / Diesel |
Condition: |
New |
Product Description
SPECIFICATIONS
Single-Cylinder,Air-Cooled,Four-Stroke,4 valve
Engine Type | Single-Cylinder,Four-Stroke,Air-Cooled, |
Max.Power (Kw/r/min) | 9.0kw/8500r/min |
Max.Torque (N.m/r/min) | 13.5N.m/6000r/min |
Bore*Stroke(mm) | 58.5mm*58.5mm |
Displacement(ml) | 148ml |
StartType | Electric |
Gearshift | Wet Multi-Plate,international 5 gears |
Seat hight(mm) | 765mm |
Min,turn radius | 2560 |
Min.Ground Clearance (mm) | 165mm |
Brake Mode(Fr./Re) | Disc/Disc |
Front Tire | 80/90-17 |
Rear Tire | 130/70-17 |
Lgnition | C.D.I |
Fuel Tank Capacity(L) | 15L |
Front suspension | Front reverse shock absorber |
Rear suspension | Rear mono shockabsorber |
Battery | 12V7Ah |
Max.Speed (km/h) | 95km/h |
Max Loading capacity(kg) | 150kgs |
Climbing Ability | 22 |
Wheelbase(mm) | 1310mm |
Dimension (mm) | 1940x770x1035 |
Lubricate | Pressure splashes |
Compression Ration | 10.6:1 |
Net Weight(kg) | 127kgs |
Quantity 20FT/40FT/40HQ | 24/50/75(units) |
CKD(40HQ) | 100(units) |
Other engine displacement | 125cc/150/cc/200cc |
