Specifications
Prod Model: |
S43 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Load Capacity: |
≤100kg |
Accessories: |
LED Light |
Certification: |
CE |
Folded: |
Folded |
Voltage: |
24V |
Product Description
1. With CE certificate
2. Designed for the elder, the handicapped and the people can't walk smoothly.
3. Aluminium alloy frame.
4. Simple operation, portable, economy and environment protection.
5. Power driven, no air pollution, no noise, all closed-end battery, no leakage of concerns, and low power consumtion
6. Sturdy and stylish steel tubing Offers good performance on indoor and smooth outdoor surfaces
7. The scooter operated easily, even a child can control it.
Pushing dial rocker controller softly can move forward or backward.
The speed is adjustable during the moving.
Pushing the controller back can make the electromagnetic brack act at once and let the scooter stop stably.
8. Imported motors and controller
9. The application confine: Park, plaza, hospital, exibition center, shopping center, museum, airport
Item |
S43-20AH |
The extemal dimension (length× width× height)mm |
1030× 530× 890 |
Front wheel |
170× 50× 2 (PU Solid tyre) |
Back wheel |
190× 70× 2 (PU Solid tyre) |
Seat |
Adjustable Height |
Speed |
≤ 8km |
Ranges |
about 22km |
Duration |
about 3H |
Groove Crossing Ability |
50mm |
Rear wheels |
Rear Wheels Driving |
Electro-magnetic brake |
Electro-magnetic Brake |
Weight |
46kg |
Weight Capacity |
100kg |
Ground Clearance From Seat |
520mm-560mm |
Min. Turning Radius |
1000mm |
Max. Slope Grade Ability |
10± 1 |
Countroller |
70AMP |
Motor |
270W |
Changer |
DC24V 2A AC 180-250V |
Batteries |
12V 20AH× 2PCS |
