Specifications
| Prod Model: | LKG-400 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: | EEC |
| Displacement: | >400CC |
| Transmission: | Shaft |
| Start-up: | Electric |
Product Description
Certificate EECPatent Number 000 936 026 - 0001
Length*Width*Height, mm 2530*1456*1420mm
Wheel base, mm 1985mm
Track, mm a Front 1278mm
b Rear 1177mm
Ground clearance, mm 320mm
Brakes (front/rear) Hydraulic Disc, Foot Control
Dry weight, kg 355kg
Minimum turning radius, m 3.5m
Maximum, km/h 75km/h
Engine a Model 179F
b Type Liquid cooled and strong wind-cooled, 4-stoke
c Displacement, ml 359ml
d Bore, stroke, mm
e Compression 8.6: 1
f "Rated power(Speed)
Kw(r/min)" 13.5kw or 5500rpm
g "Maximum torque(Speed)
Nw(r/min)" 24Nm or 4000rpm
Starting Electric and Hand
Driving Shaft
Clutch Automatic, Centrifugal, Dry, Shoe Type
Ignition CDI
Battery 12V 14AH
Tank capacity, L 12L
Tires(off road) a Front 21x8-10
b Rear 22x11-10
Warranty Within 8000km drive
Body colours Orange, Green. Red, Black, Yellow
NW/GW: 355kg/
Carton Measurement (L x W x H) in mm:
Container Load 20' GP FCL: 8PCS
40' HQ FCL: 24PCS
Minimum Order Quantity: 8 PCS
