Home Zhejiang Peace Industry And Trade Co,.Ltd ATV (TPATV50-1)
Specifications
| Prod Model: | TPATV50-1 |
|---|---|
| Certification: | EPA |
| Displacement: | 50CC |
| Transmission Type: | Automatic |
| Structure: | Two Side Doors |
| Engine Type: | 4 Stroke |
| Transmission System: | Chain Drive |
Product Description
Engine: 50CC, Single cylinder, air cooling, 4 strokeL× W× H(mm): 1240x670x870
Wheel base: 840mm
Seat height(mm): 590mm
Ground clearance(mm): 80mm
Brake: Front drum disc(R)
Transmission system: Chain
Tire: 145/70-6(F) 145/70-6(R)
Load(kg): 75kg
Fuel tank capacity(gallon)(L): 2L
Climbing capacity: ≥ 17°
Maximum speed(km/h): 40km/h
Starter system: Electric starter
Maximum power(Kw/rpm): 2.3kw/7000rpm
Maximum torque(Nm/rpm): 3.0nm/5500-6500rpm
N. W. /G. W.: 68kg/82kg
Carton size: 1160x680x660mm
Container: 48PCS/20'Qty 102PCS/40'Qty 128PCS/40'HQ
