Specifications
| Prod Model: | HSATV705 |
|---|---|
| Markets: | North America,South America,Africa,Western Europe |
| Certification: | CE |
| Transmission System: | Chain Drive |
| Engine Type: | 4 Stroke |
| Transmission Type: | Manual |
| Displacement: | 250CC |
| Fuel: | Gas |
| Structure: | All Terrain Vehicle |
Product Description
EngineType: 4-stroke
Displacement: 230CC
Cooling: Air cooling
Ignition Type: C. D. I
Number of Cylinder: 1
Compression Ratio: 9.2: 1
Bore and Stroke: 67x65
Max Power: 11.5/7000
Max Torque(N...M/r/m): 16.5/5500
Starting: Electric
Gas Tank Capacity [L]: 12.5
Engine Oil Capacity[L]: 1.2
Lighting: Yes
Top Speed [Kph]: 65
Battery Type: 12V 9Ah
Transmission
Type: Manual
Drive System Type: Chain Drive
Reverse: Yes
Gearing: 4-speed+reverse
Tires
Front Size(''): 21× 7-8
Rear Size(''): 20× 9.5-8
Product Dimensions
Length [mm]: 1820
Width [mm]: 1200
Height [mm]: 1100
Dry Weight [kg]: 175
Seat Height [mm]: 810
Wheelbase [mm]: 1240
Weight Capacity [kg]: 150
Ground Clearance[mm]: 160
Carton Dimensions
Length[mm]: 1680
Width[mm]: 1150
Height[mm]: 860
Packing Weight [kg]: 195
Cubic Meter[m3]: 1.66
Shipping Info
FOB Shipping Port: Chongqing
Est production finishing date: 20 working days
Units Per 40ft HC: 42
Units per 20ft: 12
Optional Outfits
Meter: N. A
Reverse/neutral indicator: Standard
Turning lights: N. A
Rear view mirrors: Available
Hand protector: Available
Rear carrier: N. A
Road/Street tire: Available
Off road tire: Standard
Right foot pedal(rear brake): Standard
Engine remoter: N. A
Engine displacement: N. A
Steel rim: Standard
Camo color: N. A
Tire size: N. A
Winch: N. A
