Product Description
1) Dimensions (L x W x H): 1100 x 610 x 750mm
2) Min. Ground clearance: 100mm
3) Wheelbase: 600mm
4) Tread: 470/500mm
5) Net weight: 71kg
6) Max. Load: 40kg
7) Max. Speed: 30km/h
8) Emission norm: Co: 3. 8% HC: 800ppa
9) Engine model: 1P39FMB-E
10) Engine type: Single cylinder, air-cooled, 4-stroke
11) Cylinder diameter: 39mm
12) Piston displacement: 41. 4mm
13) Cylinder work capacity: 49. 5ml
14) Compression ratio: 8. 9: 1
15) Starter system: Electric
16) Lubrication: Pressure / splash
17) Ignition type: C. D. I
18) Max. Power: 2. 0/7500kW/r/min
19) Max torque: 2. 5/5000N. M/r/min
20) Clutch: Wet multi-plate type
21) Transmission type: Chain
22) Front tire: 145/70-6
23) Rear Tire: 145/70-6
24) Brake: Drum
25) Carburetor type: PZ12J
26) Fuel tank capacity: 3. 4L
27) Lubricant capacity: 0. 8L
Established in 1995, Chongqing Chaoyue Especial Vehicle Manufacturing Co.,Ltd. is a company specialized in producing ATVs, ATV parts and dirt bikes. All the metal fittings of ATV in Chongqing market are supplied by our company. And our annual output of ATV is 50,000pcs.
We have exported our products to overseas companies, such as KPX LLC, National Custom Motorworks, ICP (UK) Fair Hawk Motors, etc. and our products are specially popular in American market. Now we are trying to further expand our overseas market, and are searching for reliable business partners worldwide.
We excel in good quality and own the most reliable and accurate database of motorcycle market. Our partners are widely located in the world, and their businesses are carried out well. For this reason, we can guarantee our best quality and service.
For any more information, please do not hesitate to contact our head office.
