ATV (ATV50-1)

Specifications

Prod Model:	ATV50-1

Product Description

Engine Type: 2-Strokes, Air Cooled, fully-automatic LC1E41QMB
Cylinder Arrangement: Single Cylinder
Transmission System: Chain Drive
Bore x Stroke (mm): 41*37
Piston Displacement (cc): 49
Compression Ratio: 7.8: 1
Maximum Power (kw/r/min): 2.4/5900
Maximum Torque (N. M. /rpm): 3.9/5500
Starter System: Electric Stater
Lubrication: Oil Injection
Transmission: Single speed
LxWxH(mm): 1335*730*780
Wheel Base (mm): 828
Front Track (mm): 530
Rear Track (mm): 530
Seat Hight (mm): 542
Ground Clearance (mm): Max. 110
Rider Capacity: 1 person
Gross Weight(kg): 68
Dry Weight (kg): 90
Brake (Front/Rear) Drum/Disc
Tyre, Front: AT16*8-7
Tyre, Rear: AT16*8-7
Air pressure(front tyre)(kpa: 20
Air pressure(rear tyre)(kpa): 20
Ignition Type: C. D. I.
Fuel Tank Capacity (L): 3.2
Engine Oil Capacity (L): 0.6
Front Suspension: Double A-Arm
Rear Suspension: Single Swing
Parking Brake: Mechanical
Max. Speed(km/h): 23
Max. Load Capacity (kg): 45
Battery: 12v/5A
Packing size(mm): 1310*750*630
Cooling system: Air-cooled
Clutch: Auto
QTY/Container: 36units/20'; 81units/40'; 108units/40'HQ
