Specifications
| Prod Model: | ATV-021 |
|---|
Product Description
Dimension(LXWXH): 1700m*1030*1100mmTire(Front/Rear): 21*8-10/22*11-8
Max speed: 55km/h
Transmission: chain/shaft
Engine type: 4-stroke, Single-Cylinder, Forced Air-Cooled
BoreXStroke: 61x49. 5mm
Efficient capacity: 144. 6ml
Rated power and rotate speed: 8. 7kw/8500R/Min
Max-torque and rotate speed: 9. 5N. m/7500R/Min
Compressing ratio: 8. 6: 1
Gearshift mode: 4 front 1 back
Starting system: Electric
Stroke: 4-stoke
Brake system front/rear: Drum/Disk
Fuel tank: 7. 5L
Steering angel: 30
Ignition: CDI
Packing:
Gross weight: 190kg Net weight: 165kg
Carton size: 1700X1100X850mm
LOADING Q'TY:
14pcs/20" 28pcs/40" 42pcs/40"HQ
