Specifications
Markets: |
North America,South America,Eastern Europe,Oceania,Western Europe |
Fuel: |
Gas / Diesel |
Transmission System: |
Shaft Drive |
Engine Type: |
4 Stroke |
Transmission Type: |
Automatic |
Displacement: |
>400CC |
Certification: |
EEC, CE |
Product Description
Engine: 498CC, 4-stroke, 1-cylinder, liquied-cooled, 4-valve
Transmission: CVT with reverse, High/Low-2speed sub-transmission
Overall length: 2, 133mm (83.9 in)
Overall Width: 1, 181mm (46.4 in)
Seat height: 865mm (34 in)
Ground clearance: 252mm (9.9 in)
Wheelbase: 1, 300mm (51.2 in)
Dry Weight: 285.7kg (629.8 lbs. )
F/R suspension: Independent, double wishbone. Coil spring, oil damped.
Front Brake: Disc, twin
Rear Brake: Sealed oil-bathed multi-disc
Ignition type: CDI
Fuel tank capacity: 22.1L (5.8 US gal. )
Bottom protection: Iron
Front And Rear Swing Arm: Aluminum
Units per 20"/40" 40"HQ: 11PCS/20'FCL 24PCS/40'HQ.
