Specifications
Prod Model: |
DR681 |
Start-up: |
Electric |
Transmission: |
Shaft |
Displacement: |
>400CC |
Certification: |
EEC |
Product Description
Pls take your time to browse our web site for more information about this product.
1) Engine type: CFMOTO 500CC, water cooled, with inner reverse
2) Power Max.: 24km/6500r/min
3) Tour Max.: 38.8N. M/5500r/min
4) Cylinder bore: 87.5mm
5) Start mode: Electric
6) Power sourc: Battery 12V18HA
7) Displacement: 493 ML
8) Comperession ratio: 10: 1
9) Ignition: CDI
Performance
1) Top speed: 80km/h
2) Starting: <15s
3) Parking trig: Mechanical lock
4) Fuel: RQ-90(leadless)
5) Lubricate oil brand: SAE15W-40/SF
6) Gas tank capacity: 16L
7) Engine oil capacity: 2.2L
8) Headlight: 12V35W
9) Tailight: 12V21w/5w
10) Climb capacity: 18 degree
Chassis
1) Distance between wheels: (F/R)1, 340mm/1, 340mm
2) Seat distance: 450mm
3) Front brake hydraulic DISC brake by foot control
4) Rear brake: Hydraulic DISC brake by foot control
5) Tire(F/R): 25X8-12' / 25X10-12'
6) Wheel base: 2340 mm
7) Seat: Double
Transmission
1) Transmission: Shaft (4X4)
2) Clutch: AUTO
Available options
1) Wheel hub: Aluminum
2) Front /rear tire: Road tire, cross-country tire
3) Rearview mirror: With EC, or without EC
4) Headlight: Four headlights with EC
Others
1) Frame: Steel tube
2) Front suspension: Double A arm
3) Rear suspension: Swing type
Packing:
N. W.: 450KG
G. W.: 520KG
Steel frame and carton
Carton dimensions: 3, 000mm x1, 680 x 880 mm
Conveyance:
20FCL: 4PC
40'HQ: 12PCS
