Specifications
Prod Model: |
SD450-02 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Cylinder Quantity: |
1 |
Fuel: |
Gas / Diesel |
Condition: |
New |
Certification: |
EEC |
Starting System: |
Kick Start and Electric Start |
Engine: |
4 Stroke |
Displacement: |
249CC |
Product Description
Engine
Engine mode: LD196MR
Engine type: Single cylinder, Liquid -cooled 4-valve SOHC engine
Displacement: 449ml
Bore & stroke: 96mm × 62.1mm
Compression ratio: 11: 1
Max. Power: 32kw/7500rpm
Max. Torque: 42.5N. M /6500rpm
Ignition system: CDI
Starting system: Electric and kick
Clutch system: Wet type, multi -plate
Gearshift type: 5-speed
Fuel system: Carburetor
Chassis
Chassis: Alloy aluminium
Measurement (L× W× H): 2175× 810× 1240mm
Front Tire: 80/100-21''
Rear Tire: 110/100-18'' / 110/90-19''
Front Brake: 240mm Single disc
Rear Brake: 240mm Single disc
Front suspension: Rebound compression damping inverted adjustable cartridge fork with 250mm travel
Rear suspension: Spring preload with rebound compression damping adjustable single-shock with 115mm travel
Dimension
Wheelbase: 1505mm
Seat height: 960mm
Ground clearance: 330mm
Fuel capacity: 8.5L
Net weight: 118KG
