Specifications
Prod Model: |
AT1505 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Fuel Tank Capacity: |
8L |
Load Capacity: |
350kg |
Ground Clearance: |
160mm |
Seat Height From Ground: |
70cm |
Wheel Base: |
1000mm |
Front Tire Spec: |
21X7-10 |
Rear Tires Spec: |
20X10-10 |
Transmission: |
Automatic with Inside Reverse Gear |
Ignition Type: |
Cdi |
Max Torque: |
10nm/5500rpm |
Transmission Type: |
Automatic |
Engine Type: |
4 Stroke |
Structure: |
Without Door |
Displacement: |
150CC |
Transmission System: |
Chain Drive |
Fuel: |
Gas / Diesel |
Brake Type: |
Drum Brake |
Maximum Speed: |
50-75 km/h |
Certification: |
CE |
Product Description
AT1505-A
Key Specifications:
Engine type: 150cc, 4 storke
Max torque: 10Nm/5500rpm
Max power: 9.3kw/7500rpm
Ignition type: CDI
Transmission: Automatic with inside reverse gear
Brake (Front/Rear): Drum/Disc
Starting system: Electric start
Battery spec: 12V, 9AH
Front suspension details: Double A x swing arm
Rear suspension details: Mono shock swing arm
Front tire spec: 21x7-10 rear tires spec: 20x10-10
Vehicle dimensions: 250x100x118cm
Wheel base: 1000mm
Seat height from ground: 70cm
Ground clearance: 160mm
Load capacity: 350kg
Fuel tank capacity: 8L
AT1505-B
Key Specifications:
1. Engine type: 200cc, 4 storke
2. Max torque: 10Nm/5500rpm
3. Max power: 9.3kw/7500rpm
4. Ignition type: CDI
5. Transmission: Automatic with inside reverse gear
6. Brake (Front/Rear): Drum/Disc
7. Starting system: Electric start
8. Battery spec: 12V, 9AH
9. Front suspension details: Double A x swing arm
10. Rear suspension details: Mono shock swing arm
11. Front tire spec: 21x7-10 rear tires spec: 20x10-10
12. Vehicle dimensions: 250x100x118cm
13. Wheel base: 1000mm
14. Seat height from ground: 70cm
15. Ground clearance: 160mm
16. Load capacity: 350kg
17. Fuel tank capacity: 8L
Package:
18. Net weight: 185kg
19. Gross weight in carton: 200kg
20. Container: 20pcs/20ft, 30pcs/40ft, 36pcs/40HQ
