2WD/4WD 800 Utility Vehicle

Specifications

Prod Model:	800UTV

Product Description

Overall dimension (LxWxH): 2975X1473X1780 mm
Wheel base: 2090 mm
Front track: 1270mm
Rear track: 1206mm
Max load weight: 650 kg
Capacity of oil tank: 26L
Turning radius: ≤4 m
Min Ground Clearance: 270mm
Top speed: 80km/h
Engine
Type: 3-cylinder, 4-Stroke, Liquid-cooled
Bore X Stroke: 68mmx72mm
Displacement: 786 CC
Compression ratio: 8.7: 1
Carburetor: HGH201
Max Power: 26.2kw/5300rpm
Maximum Torque: 57/2500~3000Nm/r/min
Starting: Electric
Lubrication: Force & Splash
Transmission: Automatic clutch, 4shift/Reverse, shaft drive, 2WD/4WD
Spark Plug: T4196J
Plug gap: 0.7-0.8mm
Battery: 12V45Ah
Headlight: 12V/35Wx2
Spot light: 12V/55W
Tire Size: Font25X8-12 Aluminum alloy rim
Rear25X10-12 Aluminum alloy rim
Suspension
Front: Double Swing A-arm
Rear: Double Swing A-arm
Brake system
Model: Four disc
Parking method: Mechanic/Hydraulic
Quantity: 8 PCS/40'HC
