200CC-250CC PALM CIVET Water-cooled ATV For Adult (BK-200W)
| Price: | Negotiable |
|---|---|
| Trade Terms: | By Sea |
| Min Order: | 10/Piece |
| Prod Model: | BK-200W |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Oceania,Mid East,Western Europe |
| Certification: | CE |
| Transmission System: | Chain Drive |
| Engine Type: | 4 Stroke |
| Structure: | Multi-door |
| Transmission Type: | Manual |
| Displacement: | 200CC |
Product Description
Model:BK-200W (water cooled,double arm)Features:
1) Engine type: single cylinder, water-cooled, 4-stroke
2) Max. speed (km/h): 90
3) Transmission system: chain drive
4) Piston displacement (ml): 200cc
7) Maximum power: 12.5/8000
8) Maximum torque (Nm/rpm): 15.0/6000
9) Starting system: only electric start
10) Seat height (mm): 720
11) Ground clearance (mm): 110
12) Brake (front/rear): drum/disk
13) Front tire: AT 19 x 7-8/2.9psi
14) Rear tire: AT 18 x 9.5-8/2.9psi
15) Ignition type: CDI
16) Fuel tank capacity (L): 4.5
17) Fuel no.: RQ 90
18) Lubrication type: pressure, splash
19) Idling/turning speed (rpm): 1500
20) Front suspension: wishbone suspension
21) Rear suspension: mono-shock swing arm
22) Climb capability: 30
23) Engine oil capacity (L): 0.9
24) Parking brake: mechanical lock
25) Battery: 12V 9Ah
26) Gear oil capacity (L): 0.11
27) Rider capacity: 1 person
28) Rear track (mm): 760
29) Front track (mm): 810
30) Compression ratio: 10.16:1
31) Cylinder arrangement: single cylinder
32) Axle base (mm): 1110
33) Lubrication: press splash
Conveyance: 29PCS/20'FCL 64PCS/40'FCL 66PCS/40'HQ
YongKang BinKai Industry & Trade Co., Ltd. Is a famous professional manufacturer of Whiplash Scooter, Dirt Bikes, ATVs, in Yongkang city, China.
Which is reputed as the capital of metal and hardware in China, Yongjiang company covers an area of 60, 000 square meters with more than 800 employees. Equipped with 1 R&D center, 1 steel frame factory, 1 plastic frame factory, 4 production lines and 1 vehicle testing line.
Conforming to ISO 9001: 2000 standard, we have always been attaching special importance to the quality control and management. Our products have GS and CE approvals. Providing our customers with excellent products and good service is our perpetual goal. The clients from all over the world are sincerely and warmly welcomed.
Which is reputed as the capital of metal and hardware in China, Yongjiang company covers an area of 60, 000 square meters with more than 800 employees. Equipped with 1 R&D center, 1 steel frame factory, 1 plastic frame factory, 4 production lines and 1 vehicle testing line.
Conforming to ISO 9001: 2000 standard, we have always been attaching special importance to the quality control and management. Our products have GS and CE approvals. Providing our customers with excellent products and good service is our perpetual goal. The clients from all over the world are sincerely and warmly welcomed.
