Price: | Negotiable |
---|---|
Trade Terms: | FOB |
Min Order: | 2/Piece |
Pay Type: | L/C,T/T |
Specifications
Prod Model: | FPG1100E |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Maximum Speed: | >90 km/h |
Start-up: | Electric |
Transmission: | Shaft |
Displacement: | >400CC |
Certification: | EEC |
Product Description
1)1100CC 4-seats dune buggy 4x4 road legal
Engine type |
LJ465Q-1ANE1 4-cylinder, 4 stroke, water cooling, inline, multiple spherical combustion chamber, overlapping camshaft, electronic fuel injection and electronic control ignition |
Engine brand | LIUZHOU WULING |
Displacement | 1.1L |
Cooling | WATER COOLED |
Max horsepower | 51.6HP, 38.5KW |
Max torque | 65.5mm |
Max speed | 90km/h |
Climbing ability | 55 |
Ignition | electronic fuel injection and electronic control ignition |
Max speed | 80km/h |
Brake system (front/rear) | Disk/Disk |
Gearshift mode | Automatic clutch,five speeds,one neutral with inside reverse gear |
Starting system | ELETRICAL |
Battery | 12V/ 45AH |
Carburetor brand | SIEMENS |
Engine oil | API SP SAE 10W/30 |
Gear oil | Gear oi GL |
Transmission | FIVE SPEEDS, ONE NEUTRAL |
Driveline | SHAFT |
Driving wheel | 2W |
Suspension, front/rear | TWO SUSPENSIONS |
Brakes, front/rear | DISC |
Brake operation | FOOT&HAND |
Tires, front/rear |
FRONT 28×10-14 REAR 28×12-14 FRONT 7×8-12 REAR 27×11-12 |
Fuel capacity/type | 30L |
Weight N.W. | 850kgs(1872.2lbs) |
Max load | 350kgs(770.9lbs) |
Wheelbase | 3200mm(126in) |
Height to seat | 520mm |
Min ground clearance | 35mm |
Steering angle | 36 |
Quantity |
1),2 units/20″;4 units/40″;8 units/40HQ 2),4 units/20″;8 units/40″;16 units/40HQ |
Packing Size | 1),2980*1650*1250 |
