Home Panan Jiadesheng Industry And Trade Co., Ltd. 11.0kw/7500rpm 250cc ATV Et-ATV029 150cc-250cc ATV
11.0kw/7500rpm 250cc ATV Et-ATV029 150cc-250cc ATV
| Price: | US $ 800-1000/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
Specifications
| Prod Model: | wv-atv027 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Transmission System: | Chain Drive |
| Transmission Type: | Automatic |
| Certification: | CE |
| Engine Type: | 4 Stroke |
| Fuel: | Gas / Diesel |
| Displacement: | 250CC |
| Structure: | Without Door |
| Maximum Speed: | 50-75 km/h |
| Brake Type: | Disc Brake |
Product Description
Engine :
l 250CC, 4-stroke, single cylinder, air-cooling
l Max. power: 11.0kw/7500rpm
l Starting system: electric
l Transmission:5 speeds forward / 1 reverse Clutch: manual
Chassis:
l Brakes (Front/rear): drum/Hydraulic disc
l Absorber (front/rear):ballonet - absorber
l Tires(Front/Rear): 19x7-8 /18x9.50-8
l Drive train: Chain Fuel capacity: 8L
Dimensions:
l Wheel base:1075mm Seat height:800mm
l Ground clearance: 160mm
l Products size: 1450×8500×930mm
l Max speed: 85km/h
l Max load capacity: 200Kgs
Packing:
l G.W:159kgs N.W:148KGS
l Package measure: 1500x820x800cm
Conveyance:
l Qty/20Fcl: 20pcs Qty/40Fcl: 30pcs Qty/40HQ: 66pcs
| ENGINE | |||
| Engine Type: | Single-cylinder,4-stroke,water-cooling | ||
| Transmission: | 5 speeds forward/1 reverse | clutch | manual |
| Displacement (ml): | 250 | ||
| Max. Power (kw/r/min): | 13.0/8500 | ||
| Max. Speed (Km/h): | 110 | ||
| Starting System: | Electric | Absorber | ballonet-absorber |
| CHASSIS | |||
| Final Drive: | Chain drive | ||
| Front/Rear Brake: | drum/hydraulic disc | Front Tire: | 21*8-10 |
| Rear Tire: | 0022*10-10 | ||
| DIMENSIONS | |||
| L X W X H (mm): | 1450×850×930 | Seat Height (mm): | 900mm |
| Wheel Base (mm): | 1105 | ||
| Ground Clearance (mm): | 210 | ||
| Dry. Weight (kg): | 159 | ||
| Packing Weight (kg): | 179 | Max. Load Weight (kg): | 220kg |
| Fuel Tank Capacity (L): | 8L | ||
| OTHERS | |||
| Container Loading: | 20"GP:20pcs 40"HQ:66pcs | ||
