Home Yongkang Changshun Industry & Trade Co., Ltd. 1000W /1200W /1500W Electric ATV with CE (CS-E7010)
1000W /1200W /1500W Electric ATV with CE (CS-E7010)
| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 30/Set |
| Pay Type: | L/C,T/T,Western Union |
Specifications
| Prod Model: | CS-E7010 |
|---|---|
| Markets: | North America,South America,Southeast Asia,Western Europe |
| Brake Type: | Disc Brake |
| Maximum Speed: | <50 km/h |
| Fuel: | Electric |
| Certification: | CE |
| Transmission System: | Chain Drive |
| Structure: | Without Door |
| Transmission Type: | Automatic |
| Engine Type: | Reducing Motor |
Product Description
A. Electric mini ATV with voltameter.B. Motor: 1000W/1200W/1500W
C. E-ATV with front & reverse gear.
D. with CE.
1. Battery Spec: 4PCS x 12V /20Ah
2. Charge Time: 8-11hours
3. Battery Life: About 300 cycles
4. Speed: ≤ 25 Km/h
5. Load capacity: ≤ 70kg
6. DC-DC direct current switch: Import 31V-55V/export 12V
7. Control: 48V /1000W
8. Produce Size: 1340 x 170 x 820mm
9. Carton Size: 1240 x 775 x 600mm
10. Brake Way: Front Drum Brake/Rear Disc Brake
11. Drive Way: Chain Drive
12. Wheel Rim: Iron
13. F/R Suspension: F&R Hydraulic pressure
14. N. W.: 100kgs
15. G. W.: 112kgs
16. Wheel Size: 145/70-6/145/70-6
