Off Road Sports Motorcycle (JY125T-7)

Specifications

Prod Model:	JY125T-7

Product Description

Engine type: Air cooled, 4 stroke, single cyclinder
Stroke: 57. 80mm
Displacement: 124. 65ml
Max. Power output: 5. 4kw/8000min.
Max. Torque: 7. 4n. M/6000min.
Appr. Fuel consumption: 2. 8L/100km
Starter system: Electric/kick
Demensions(lxwxh): 1855*735*1060mm
Wheelbase: 1310. 00mm
Ground clearance: 115. 00mm
Fuel capacity: 6. 5L
Suspension(fr. /rr. ): Hydraulic-pressed spring style/hydraulic-pressed spring style
Brakes front/rear: Disc/drum
Dry weight: 103. 00kg
Wheel size(fr. /rr. ): 3. 0*10/3. 5*10
Wheel type: Alloy
Colors: Blue, silver white
Package 1: Carton+iron frame
Packing size 1: 1690*565*1120mm
Disassembled parts: Fr. Wheel, fr. Mudguard, rr. Handle, rr. View mirror,
Load q'ty 20'gp=26units 40'gp=56units 40'hq=56units
Package 2: Wooden box
Packing size 2 (a): 1860*740*1060mm
Disassembled parts: Fr. Wheel, fr. Mudguard, rr. Handle, rr. View mirror,
Load q'ty 20'gp=18units 40'gp=38units 40'hq=38units
Packing size 2 (b): 1670*620*860mm
Disassembled parts: Fr. Wheel assy., head assy., seat, tail cover, rr. Handrail, cover of handbar, fr. Panel, fr. Fender, rr. Mirror, electrolyte & battery
Load q'ty 40'hq=78units
