New Style Utility Vehicles(UTVs), Dirt Bike,ATV

Specifications

Prod Model:	EYK250-2RP(LBC250V)

Product Description

LBC250V Utility Task Vehicle
Specifications
Overall length 2600mm
Overall width 1250mm
Overall height 1925mm
Wheelbase 1685mm
Front track 1100mm
Rear track 1150mm
Ground clearance 200mm
Packing size 2300x1300x1120mm
Engine type 1-cylinder, liquid-cooled,4-stroke
Bore x stroke 57.4x57.8
Displacement 249.5ml
Compression ratio 9.2:1
Output power 7.4kw/7500rpm
Maximum torque 9.5/5500n. M/R/min
Starting electric
Ignition cdi
Lubrication force & splash
Transmission automatic cvt
Spark plug
Load 2 rider or 150kg
Fuel tank 20 l
Engine oil capacity 850ml
Starting time 5s
Climbing angle 20 -25
Max. Speed 55km/h
Battery 12v9ah
Head light 12v21w
Tail light 12v21/5w
Turning light 12v10w
Horn 12v5w
Fuse 10a
Front brake hydraulic -
Rear brake hydraulic disc/right foot control
Front tire at19x7.0-8/98kpa
Rear tire at22x10-10/98kpa
Suspension-front 2- a-arm, liquid damp
Brake track <7m@30km/h
Dry weight 380kg
Gross weight 470kg
