Go Kart 1100CC Dune Buggy 4X4 with 4 Seater
| Price: | Negotiable/Piece |
|---|---|
| Trade Terms: | FOB |
| Min Order: | 1/Piece |
| Pay Type: | T/T |
Specifications
| Prod Model: | LANDMAX 1100TR4 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certificate: | EPA |
| Others: | F/R Locking Differential |
| Transmission System: | Shaft Drive |
| Transmission Type: | Manual |
| Final Drive: | 2WD & 4WD Switch |
| Cooling System: | Water Cooled |
| Engine Type: | 4 Stroke |
| Brake Type: | Brake Disc |
Product Description
Manufacturer of go kart, buggy, dune buggy, racing go kart, beach buggy, buggy 4x4, 4X4 buggy, off road buggy, sand buggy, dune buggy 4x4, 4x4 dune buggy, go kart 4x4, 4x4 go kart.Lannmarker 1100cc Side by Side 4X4 with 4 Seater
- 1100cc Water-cooled EFI Engine
- Manual 5-Speed - Hydraulic Clutch
- Shaft Drive 2WD & 4WD Switch
- Front and Rear Locking Differential
- Independent Rear Suspension (IRS)
| SPECIFICATION | |
| ENGINE | |
| Engine Type | In-Line Four Cylinder, 16- Valve DOHC |
| Displacement | 1083cc |
| Bore x Stroke | 72 x 66.5mm |
| Compression | 9.5: 1 |
| Fuel System | Electronic Fuel Injection |
| Cooling System | Water Cooled |
| Ignition | ECU |
| Max. Power Output | 50 kw/6000r/min |
| Max. Torque | 90 N. M/4000r/min |
| Fuel Capacity | 42L (11.1Gal) |
| Transmission Mode | Manual 5-Speed - Hydraulic Clutch |
| Final Drive | 2WD/4WD Front and Rear Locking Differential |
| Top Speed | 90 KM |
| Wheels and Brakes | |
| Front/Rear Tyres | 27*8-14 / 27*10-14 |
| Front Suspension | Independent, Double Swing Arm |
| Rear Suspension | Independent, Trailing Dual Swing Arm |
| Front/Rear Brakes | Hydraulic Four Wheel Disc |
| Dimensions and Weight | |
| Product Dimension(LxWxH) | 4, 020 X 1, 600 X 1, 990mm |
| Carton Dimension(LxWxH) | 4, 125 X 1, 810 X 1, 150mm |
| Payload Capacity | 340 kg |
| Wheelbase | 3, 250 mm |
| Ground Clearance | 300 mm |
| Dry Weight | 870 kg |
| Gross Weight | 1210 kg |
| Container Loading | 4 units/40' HQ |
