Specifications
Prod Model: | FPA500E-b |
---|---|
Certification: | EEC |
Transmission System: | Shaft Drive |
Engine Type: | 4 Stroke |
Structure: | Two Side Doors |
Transmission Type: | Semi-Automatic |
Displacement: | >400CC |
Product Description
EEC 500cc QuadEngine | 471CC,Water cooled,4-stroke,1-cylinder |
Bore x Stroke | 84.5mm x 84mm |
Compression Ratio | 9.4:1 |
Carburetion | PD33J-A |
Ignition | CDI |
Starting | Electric/pull |
Transmission | L-H-N-R-P |
Drive Train | Axle |
Max power | 17.0kw/5000-5500rpm, 22.8HP |
Max torque | 35.0N.m/4500rpm |
Suspension | Independent double swing arm |
Suspension/Rear | Independent double swing arm |
Brakes/Front | Dual ventilated hydraulic disc |
Brakes/Rear | Ventilated Hydraulic disc |
Tires/Front | AT25 x 8-12 radial |
Tires/Rear | AT25 x 10-12 radial |
Dimension | 1990mm x 1060mm x 1150mm |
Seat Height | 820mm |
Wheelbase | 1235mm |
Ground Clearance | 220mm |
Fuel Capatity | 13.6L |
Dry Weight | 278kg |
Loading Capacity | 20’ft/10pcs 40’ft/24pcs 40’HQ/36pcs |
