Specifications
| Prod Model: | LKG-250 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: | EEC |
| Displacement: | >400CC |
| Transmission: | Shaft |
| Start-up: | Electric |
Product Description
Certificate EEC-e9*2002/24*0291*00Patent Number 000 936 026 - 0001
Length*Width*Height, mm 2, 530*1, 457*1, 426mm
Wheel base, mm 1, 985mm
Track, mm a Front 1, 278mm
b Rear 1, 177mm
Ground clearance, mm 285mm
Brakes (front/rear) Hydraulic Disc
Dry weight, kg 345kg
Minimum turning radius, m 3.5m
Maximum, km/h 70 km/h
Engine a Model 172MM-C
b Type Liquid cooled, single cylinder, 4-stoke
c Displacement, ml 244 ml
d Bore, stroke, mm 72mm x 60mm
e compression 10.0: 1
f "Rated power(Speed)
Kw(r/min)" 11kw or 7000rpm
g "Maximum torque(Speed)
Nw(r/min)" 17.6Nw or 5500rmp
Starting Electric
Driving Shaft
Clutch Automatic, Centrifugal, Dry, Shoe Type
Ignition C. D. I
Battery 12V, 12Ah
Tank capacity, L 9.0L
Tires(off road) a Front 22x 7-10
b Rear 22x10-10
Warranty Within 8000km drive
Body colours Orange, Green. Red, Black, Yellow
NW/GW: 345kg / 385kg
Carton Measurement (L x W x H) in mm: 2300 x 1460 x 855 mm
Container Load 20' GP FCL: 8 PCS
40' HQ FCL: 24PCS
Minimum Order Quantity: 8 PCS
