Specifications
| Prod Model: | LKG-110 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Certification: | EEC |
| Displacement: | >400CC |
| Transmission: | Shaft |
| Start-up: | Electric |
Product Description
Certificate CEPatent Number
Length*Width*Height, mm 2055*1240*1174mm
Wheel base, mm 1598mm
Track, mm a Front 1062mm
b Rear 1035mm
Ground clearance, mm 235mm
Brakes (front/rear) Hydraulic Disc, Foot Control
Dry weight, kg 160kg
Minimum turning radius, m 3.5m
Maximum, km/h 40km/h
Engine a Model LC1P52FM
b Type air cooled, single cylinder, 4-stroke
c Displacement, ml 106.7ml
d Bore, stroke, mm 52.4x49.5mm
e Compression 8.6: 1
f "Rated power(Speed)
Kw(r/min)" 4.6kw/7500r/min
g "Maximum torque(Speed)
Nw(r/min)" 6.9N. M or 5000rpm
Starting Electric
Driving Shaft
Clutch Automatic, Centrifugal, Dry, Shoe Type
Ignition CDI
Battery 12V 3AH
Tank capacity, L 4.5L
Tires(off road) a Front 19x7-8
b Rear 18x9.5-8
Warranty Within 8000km drive
Body colours Orange, Green. Red, Black, Yellow
NW/GW: 160kg/200kg
Carton Measurement (L x W x H) in mm:
Container Load 20' GP FCL: 18PCS
40' HQ FCL: 48PCS
Minimum Order Quantity: 18PCS
