Specifications
| Prod Model: | SK50ST-8 |
|---|
Product Description
Vehicle specitication:1) Dimensions(L*W*H)(mm): 1320*790*915
2) Wheel base(mm): 860
3) Min. Ground clearance(mm): 110
4) Dry weight(kg): 83
5) Max. Loading weight(kg): 75
6) Max. Speed(kw/h): 40
7) Brake method(FR/RR): Disk/disk
8) Tire size(FR/RR): 16*8-7/16*8-7
9) Seat height(mm): 760
10) Suspension/Front: Air chamber
11) Suspension/Rear: Air chamber
12) Fuel Capacity: 2L
Outer packing: Cartons with steel frame
Carton size: 1160*660*770mm
Quantity: 135pcs/40'HQ
Engine specitfications:
1) ENGINE type: 50CC-110cc, single cylinder; Air-cooled, 4-stroke
2) Bore*stroke(mm): 39.0*41.4
3) Compressing ratio: 9.0: 1
4) Max. Power and speed: 2.3kw/7000rpm(-5%, +5%)
5) Max. Torque(N. M/rpm): 3.0N. M/5500-6500r/min(-5%, +5%)
6) Starting method: Electric
7) Lubrication way: Press and splash
8) Ignition: C. D. I
9) Trasmission: 4-speed
10) Drive train: Chain
