Home Shandong Pioneer Motorcycle Co., Ltd. 250CC ATV WITH EEC
Specifications
| Prod Model: | XF250ATV-2 EEC |
|---|
Product Description
Model No XF250ATV-2 EECEngine
Type 244cc, dual-cylinder, 4-stroke, water-cooled
Bore x Stroke 72 x 60
Compression ratio 10.0:1
Ignition CDI
Transmission Stepless (automatic) with reverse
Starting system Electric starting
Rate power and rotate speed 10.5kw/7000r/min (14.2hp/7000r/min)
Final driver shaft
Chassis
Suspension/Front Independent, double A-arm, oil damped
Suspension/Rear Swing-arm ,oil damped
Brakes/Front Disc type
Brakes/Rear Disc type
Tires/Front 22 x 7-10
Tires/Rear 22 x 10-10
Dimensions
Length 1970mm (77.6")
Width 1050mm (41.3")
Height 1150mm (45.3")
Wheelbase 1260mm (49.6")
Dry Weight 225kg (495 lbs)
Fuel Capacity 7.5L (1.65 gal)
Color Red, yellow, blue, green
Container capacity 26units/40GP, 12units/20GP
