Specifications
Product Description
Feature: 125cc. 4 stroke, electrik&kick start, manual clutch, acyclic gear, front disc&rear drum, spoke wheel.
Specifications:
Engine type: Single cylinder, air cooling, 4 stroke
Clutch method: Manual
Ignition method: C. D. I.
Start method: Electric&kick start
Cylinder: Single
Transmission: Chain
Displacement(ml): 124
Bore*stroke(mm): 56.5*49.5
Compression ratio: 9.2: 1
Rated power(kw/r/min): 7.8/8000± 500
Maximum torque(N. M/r/min): 8.8/7000± 500
Lubrication: Splash
Gear: 5
Dimensions(L*W*H)(mm): 2100*780*1100
Wheel base(mm): 1300
Seat height(mm): 820
Min. Turning radius(mm): 1900
Min. Ground clearance(mm): 200
Rider capacity: 2
Brake: Front disc&rear drum
Front wheel: 2.75-18
Rear wheel: 3.00-18
Fuel tank capacity(L): 7
Engine oil capacity(ml): 800
Climbing capacity: ≥15
Max. Load(kg): 110
Max. Speed(kw/h): 100
Battery: 12V5Ah
Packing size(L*W*H)(mm): 1680*450*810
Net weight(kg): 84
Gross weight(kg): 104
