Specifications
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
|---|---|
| Certification: | EPA |
| Transmission System: | Chain Drive |
| Engine Type: | 4 Stroke |
| Structure: | Two Side Doors |
| Transmission Type: | Automatic |
| Displacement: | 250CC |
Product Description
Complete Specifications:1. Engine type: 200CC/250CC, 4 stroke, Water / Air Cooled. ZongShen Brand
2. Bore and stroke 63.5x62.2/72x62.2
3. Compression rating: 9.2: 1
4. Max torque: 13.5Nm/5500rpm, 17.5Nm/5000rpm
5. Max power: 10kw/7500rpm, 11kw/7500rpm
6. Ignition type: CDI
7. Transmission: Manual clutch, 4-speed, reverse gear, chain
8. Brake (Front/Rear): Drum /Disc
9. Starting system: Electric start
10. Battery spec: 12V, 9AH
11. Front suspension details: Double A x swing arm,: Air chamber shock absorbers
12. Rear suspension details: Inner ballonet absorber
13. Front tire spec: 19 x 7 - 8/21 x 7 - 10
14. Rear tires spec: 18 x 9.5 -8/ 20 x 10 - 10
15. Vehicle dimensions: 1800 x 1120 x 1130mm
16. Wheel base: 1150mm
17. Seat height from ground: 880mm
18. Ground clearance: 120mm
19. Load capacity: 155kg
20. Fuel tank capacity: 4L
21. Gross weight in carton: 170kg
22. Net weight: 155kg
23. Packing size: 1480 x 850 x 880mm
Capacity:
Qty/20' GP: 20 units
Qty/40' GP: 44 units
Qty/40' HQ: 66 units
