Specifications
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Start-up: |
Electric |
Transmission: |
Chain |
Displacement: |
150CC |
Certification: |
EPA |
Product Description
EPA certificated
Engine type: 4-stroke, single cylinder, air cooled
Displacement: 150CC
Max HP: 8.2 HP/7500rpm
Max torque: 7 lb ft/6000rpm
Bore x stroke: 2.26x2.28 inches
Max speed: 43.5 mph
Climbing ability: 12 degree
Ignition: C. D. I
Starting system: Electric
Battery: 12V 10Ah
Carburetor brand: Deli (Vacuum film)
Engine oil: SAE 15W-40
General Information
Clutch: Automatic CTV with reverse
Driveline / Driving wheel: Chain / Dual wheel drive
Suspension F / R: Double A-arm / Independent Swingarm
Brakes, F / R: Disc
Tires, F / R: 20x7-8 / 22x10-10
Fuel capacity: 2.25 gal
Weight, G. W. / N. W.: 573 / 485 lbs
Max load: 500 lbs
Dimension Information
Wheelbase: 59 inches
OA L x W x H: 85x53.1x57.5 inches
Height to seat: 13.8 inches
Min ground clearance: 6.7 inches
Shipping information: 40 PCS/40HQ
