Specifications
Prod Model: |
SN-GS395-XL |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color Available: |
Green, Yellow, Red, Blue |
Starting System: |
Kick System |
Certification: |
CE |
Engine: |
2 Stroke |
Displacement: |
≤50CC |
Condition: |
New |
Fuel: |
Gas / Diesel |
Cylinder Quantity: |
1 |
Product Description
1) Engine type: 49.8CC, single cylinder, AIR-cooled, 2-stroke
2) Oil type: Petrol, 1: 20 engine oil mixing
3) Rated power and rotate speed: 9HP/9500rpm
4) Max. Torque and rotate speed: 7N. M/11, 000rpm
5) Tank capacity: 5L
6) Ignition: CDI
7) Compress ratio: 11+/-0.6: 1
8) Driving mode: Chain
9) Starting system: Kick start
10) Tire (front/rear): 60/100-14/70/100-12
11)seat high: 730MM
12)Mix distance from ground: 280mm
13)front and rear weels distance: 110mm
14) Brake system (front and rear): Hydraulic disc brake
15) Dimensions (L x W x H): 1580*640*940mm
16) Max. Speed: 75km/h
17) Max. Loaded: 150kg
18)front and rear suspension: Up side down hydraulic/dydraulic
19)Rim/handle bar: Steel/Aluminium
N. W.: 47kg
G. W.: 56kg
