SKYTEAM T-REX 125cc 4 stroke on road motorcycle (EEC EUROIII EURO3 approval, 5.5-10"/5.5-10")

Specifications

Product Description

EEC EUROIII EURO3 4 stroke RV90 replica, ece vanvan replica t-rex 5.5-10"/5.5-10", 125cc chappy dirt bike

Wide big tires with much comfort

ST125-11

ENGINE
ENGINE TYPE Air-Cooled, 4 stroke, single cylinder, 2 valve, SOHC
DISPLACEMENT 124CC
BORE*STROKE 52.4 x 57mm
COMPRESSION RATIO 9.0 TO 1
MAXIMUM POWER 5.0kW/6500rpm
MAXIMUM TORQUE 7.3Nm/6500rpm
MAXIMUM SPEED 82km/h
MAXIMUM SPEED ON COC 82km/h
LUBRICATION SYSTEM Pressure and splash lubrication
CARBURETOR/FUEL SUPPLY MIKUNI 22 38419
CLUTCH TYPE Wet, multiple disc
IGNITION SYSTEM CDI
STARTER SYSTEM Electric & Kick
TRANSMISSION SYSTEM 4-gear, Pedal
FINAL TRANSMISSION Chain
FUAL TANK CAPACITY 3.8L
OIL TANK CAPACITY 800ml

CHASSIS
CHASSIS Steel, Single-tube
FRONT SUSPENSION SYSTEM Spring & Oil
FRONT TRAVEL 100mm
REAR SUSPENSION SYSTEM Spring & Oil / Double Shock
REAR TRAVEL 100mm
FRONT BRAKE Disc 155mm
REAR BRAKE Drum
FRONT TYRE 21*7.00-10(5.50-10)
REAR TYRE 21*7.00-10(5.50-10)

DIMENSIONS
LENGTH 1880mm
WIDTH 875mm
HEIGHT 1025mm
SEAT HEIGHT 760mm
WHEEL BASE 1225mm
MINIMUM GROUND CLEARANCE 205mm
DRY WEIGHT 93KGS
CONTAINER LOAD 28/58/87
PACKING DIMENSION 1600 x 530 x 870mm
