Dimensions ( length×width×height)(mm) | 2400×1650×1000 |
Wheel base (mm) | 1420 |
Tread (mm) | 1100 |
Ground clearance (mm) | 135 |
Column reach (mm) | 60 |
Angle of column | 25°30′ |
Dry weight (kg) | 320 |
Max payload (kg) | 3 Persons + 100kg |
Top speed (km/h) | 85 |
Economic speed fuel consumption ( L 100km ) | 6 |
Engine | CJ 750F |
Cylinder diameter × stroke (mm) | 78×78 |
Total displacement | 746 |
Compression Ratio | 7+/-0.2:1 |
Max power and its corresponding speed (kW/r/min) | 25/5000+200 |
Applicable gasoline | RQ-90 |
Applicable oil | HQ10 ( for summer) HQ 6 ( for winter) |
Starting mode | Kick & Electric |
Type of carburetor | PZ 28F |
Capacity of gasoline tank (L) | 22 |
Oil capacity of crankcase (L) | 2 |
Oil capacity of gear box ( L) | 0.8 |
Oil capacity of rear drive ( L) | 0.175 |
Clutch | Mechanically controlled double-disc. Dry friction |
Gear position No.1 Gear position No.2 Gear position No.3 Gear position No.4 | 3.6:1 2.29:1 1.71:1 1.3:1 |
Mode of driving shaft | One universal joint |
Speed redecing ratio of rear drive | 4.62:1 |
Tyre size (inch) | 3.75-19 |
Tyre pressure (kpa) | Front wheel 16kg /cm |
