Specifications
Prod Model: | WJ125T-18 |
---|---|
Markets: | Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Wheelbase (Mm): | 1280 |
Brake Type (F/R): | Disc/Drum |
Brake Operation Type (F/R): | (F Hand Control/R Hand Control) |
Rim Type(F/R): | Spoke/Spoke |
Tyre Size (Fr. /Rr. ): | 3.50-10/3.5-10 |
Engine Type: | 1p52qmi 1-Cylinder, 4-Stroke, Air-Cooled |
Bore Strok(Mm): | 52.4x57.8 |
Cylinder Capacity (Ml): | 124.6 |
Compression Ratio: | 9.2: 1 |
Max Power (Kw/Rpm): | 5.8/7600 |
Fuel Tank Capacity: | 5-8L |
Maximum Loading Capacity: | ≥120kg |
Engine: | 4 Stroke |
Displacement: | 51-125CC |
Max Speed: | >50km/h |
Certification: | 3C |
Product Description
Established in 2003, Taizhou Wanglong Motorcycle Co., Ltd is a professional motorcycle and scooter manufacture which is located in the Taizhou Zhejiang east of China, the town of plastic in the world. Our factory occupiesVehicle Data | Lenth*Width*Height (mm) | 1885X878X1250 |
Wheelbase (mm) | 1280 | |
Min Ground Clearance (mm) | 110 | |
Net weight (kg) | 98 | |
Max load (kg) | 150 | |
Max speed (km/h) | 85 | |
Brake type (F/R) | Disc/Drum | |
Brake operation type (F/R) | (F hand control/R hand control) | |
Rim Type(F/R) | spoke/spoke | |
Tyre size (Fr./Rr.) | 3.50-10/3.5-10 | |
Tyre Air Pressure (F/R) kPa | 175/250 | |
Engine Date | Engine Brand | WJ |
Engine Type | 1P52QMI 1-Cylinder,4-Stroke,air-cooled | |
Bore Strok(mm) | 52.4X57.8 | |
Cylinder Capacity (ml) | 124.6 | |
Compression Ratio | 9.2:1 | |
Max power (kw/rpm) | 5.8/7600 | |
Maxium Torque N·m/(r/min) | 8.01/5000 | |
Min Idling Speed r/min | 1700±100 | |
Fuel Consumption g/(kW·h) | 352 | |
Lubrication | Pressure/Splash | |
Lubricant Number | 14W/40 | |
Clutch Style | Dry Centrifugal Automatically | |
Starting System | Electrinic/Kick | |
Lgnition | CDI |
