Specifications
Prod Model: |
GW150T |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Displacement: 149.6ml
Engine: 1 Cylinder, 4 Stroke
Bore & Stroke: 57.4× 57.8
Cooling System: Air Cooled
Compression Ratio: 9.5: 1
Fuel feed: 90#
Max Power( Kw/rpm): 6.5kW/7500r/min
Max Torque(N. M/rpm): 9.0N. M/5000r/min
Max Speed: 85 kmph
Ground clearance: 150 MM
Fuel consumption: 2.5L/100KM
Ignition: CDI
Transmission: Belt
Fuel tank capacity: 5.5L
Starting System: Electric+kick start
Front Brakes: Disc brake
Rear Brake: Drum brake
Front suspension: Hydraulic Suspension
Rear suspension: Spring
Front wheels: Alum 90/90-12
Rear wheels: Alum 350-10
Wheel Base: 1230 MM
Ground clearance: 110 MM
Payload: 150KG
Net Weight: 93KG
Gross Weight: 108KG
Packing type: Steel + Carton
Size: 1810× 700× 1100 mm
Packing size: 1700× 460× 860 mm
20' container: 32 units
40' HQ container: 105 units
