Specifications
Product Description
Speciation:
1. Production dimensions (L*W*H): 2300*840*1210
2. Wheel base: 1500mm
3. Brake type(from/rear): Fr: Disc/Re: Drum
4. Max load capacity((kg): 150
5. Min. Ground clearance: 160mm
6. Tyre, front: 110/90-16, 225
7. Tyre, rear: 130/90-15, 250
8. Battery type: 12v-8AH(Airproof)
9. Dry weight: 160Kg
10. Max, speed>100km/h
11. Max xlimbing angle: 20
12. Transmission system: Chain transmission
13. Gear system: International
14. Capacity of fuel tank: 20L
15. Engine type: Single Cylinder, Double Muffler, Cam shaft on the top, 4 Stroke
16. Engine model: 163FML-2A
17. Starting type: Electric
18. Compression ratio: 9.0: 1
19. Bore*stroke: 63mm*62mm
20. Piston displacement: 193.3ml
21. Max power: 11/7500kw/r/min
22. Max torque: 14/6000n. W/r/min
