Specifications
Prod Model: |
JY125T-40 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Color: |
Red, Yellow, Black |
Engine: |
4 Stroke |
Certification: |
COC |
Fuel Tank Capacity: |
5-8L |
Folded: |
Unfolded |
Max Speed: |
80km/H |
Displacement: |
125cc |
Maximum Loading Capacity: |
150kg |
Product Description
Professional Manufacturer of 125cc Scooter
1. New stylish design/ design patent in China
2. Powerful / 4 stroke/ airl cooled engine
3. Fully automatic CVT transmission for easy driving
4. Scooter gives safety and comfort for high speed cruising
5. Maintenance-free battery
Load information: 24PCS/20ft; 72PCS/40hq
Payment terms: L/C or T/T
The min order: The 20FT container
Packing: Normal packing with label
Dilvery time: Within 30 days after receipt the payment
1,Selling points:
1,It can match multicolor and stickers
2,we can do 125C power, also do we can do 50CC and 150CC models.
3,Front and rear vacuum tire :durable,fasten, balanced ,and beautiful. the tire is wear-resisting and aiti-explosion.
4,Disc brake has high safety performance and has no noise
5,The motorcycle can install rear box and rear carrier
Scooter body parameter |
MODEL |
JY125T-40 (King-125) |
Dimensions (mm): |
1890 x 710 x 1190 |
Wheel base (mm): |
1300 |
Ground clearance (mm): |
125 |
Dry weight / Load capacity: (kg) |
120 / 150 |
Max.speed (km/h) : |
80 / 85 |
Economic fuel consuption (1/100km/L) : |
2.8 / 2.9 |
Exhaust system : |
Mute exhaust |
Fr brake / Rr brake : |
disc/drum |
Fr tyre / Rr tyre : |
110/70-14 |
Fuel tank capacity (L) : |
9 |
Battery |
12V 7AH / 12V 9AH |
Ignition |
CDI |
Front suspension : |
Spring shock |
Rear suspension : |
Spring shock absorber |
Scooter Engine parameter |
Engine mode: |
152QMI / 157QMJ |
Engine type |
1-cylinder,air-cooled, 4-stroke |
Displacement (cc) : |
124.6 / 149.6 |
Cylinder Diameter / Pinston Stroke |
52.4 x 57.8 ; 57.4 x 57.8 |
Transmission system : |
Belt CVT |
Compression ratio |
10.3:1 |
Start system : |
kick / electric |
Standard power(km/r/min): |
5.2/7500 ; 6.4/6500 |
Max. torque(n.m/r/min): |
7.3/6000 ; 8.3/7500 |
Packing information |
N.W / G.W (KG)/Packing model |
120 / 135; |
Packing model |
Full export carton package |
Packing size(mm) /20GP(CBU) |
1860 X 570 X 1180 / 26PCS |
Packing size(mm) /40HQ(SKD) |
1760 X 570 X 870 / 72PCS |
