Specifications
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Ebike Wheel Size: |
14"*2.125" |
Frame: |
Carbon Steel |
Ebike Motor: |
Brushless |
Weight: |
33kg |
Saddle: |
Comfortable |
Hub: |
Alloy Spoke Wheel with Motor |
Baking: |
Finish Baking |
Front Fork: |
Shock Absorber |
Voltage Protection: |
Under-Voltage Protection 36.4V |
Current Protection: |
Over-Current Protection 15A |
Product Description
Motor High efficiency brushless rear wheel drive
48V 350W depending on max power allowed in individual states
Battery Lithium Polymer with advanced battery management system (BMS)
48V 15Ah, removable battery
Mains charger Intelligent charge system communicates with BMS, auto stop when fully charged
48V AC100-240V DC55.1V 2A
Assisted range ≥ 40km/25miles
Maximum speed 15 mph /25kph under powered assistance
Assistance modes Throttle to 15 mph /25kph; Stepless speed regulating for cruise assistance.
Loading capacity ≤ 130kg
Controls Battery power available; Bike on / off switch; Power assistance controls
Protections Under-voltage Protection (36.4V); Over-current Protection (15A);
Speed-limit System
Bicycle weight 33kg
Product Size 1490*640*1035mm
Frame High-carbon Steel; Finish Baking: With shock absorber
Front Fork With shock absorber; Up with electro facing, down with Finish Baking
Brakes Front/Rear hub brake
Hub Alloy spoke wheel with motor
Tyres 14*2.125"
Lighting LED indicator light power from bike battery; Reflectors: Rear red,
Extra equipment Full mudguards; Front basket; Rear seat
