Specifications
Product Description
Engine type: Single-cylinder, Air-cooled, 4-stroke
Displacement::100ml
Bore×Stroke: 49.0×54.0mm
Compression ratio: 9.5:1
Max. power: 5.0kw (8000rpm)
Max. torque: 7.0N?m (6500rpm)
Starter: Kick start / Electric start
Ignition: CDI
Clutch: Wet type, muti-plate, hand operation
Transmission: Belt
Emission: EUR II/EUR III
Size (L×W×H): 1830×690×1083mm
Wheelbase: 1250mm
Ground clearance: 100mm
Wheel rim type: Alloy
Dry weight: 103kg
Max. loading: 150kg
Fuel capacity : 5.4L
Front wheel: 3.5-10
Rear wheel: 3.5-10
Brake (Front): Disk
Brake (Rear): Drum
