Specifications
Markets: |
South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
Engine Type: |
4-Stroke |
Certification: |
CQC |
Fuel: |
Gas / Diesel |
Condition: |
New |
Product Description
SPECIFICATIONS
Single-Cylinder,Air-Cooled,Four-Stroke,Four vale
ENGINE |
|
Engine Type | Single-Cylinder,Air-Cooled,Four-Stroke,Vertrcal Engine |
Displacement(CC) | 149CC |
Ignition | C.D.I |
Bore x Stroke(mm) | 49.5x62 |
Compression Ratio | 9.0:1 |
Max.Power (Kw/r/min) | 8.2kw/8500r/min |
Max.Torque (N.m/r/min) | 9.8N.m/7000r/min |
Primary Velocity Ratio | 2.769 |
Starting System | Electric/Kick Starter |
Clutch | Wet sump |
Lubrication | Pressure/Splash |
Transmission | 5 Gear |
Fuel Capacity | 13 |
Min Fuel Cons.(L/100km) | 2.2 |
Fuel Size | 90# |
Spark Size | D8RTC |
Spark Gap(mm) | 0.6~0.7 |
Lubrication Oil Vol(L) | 0.9 |
CHASSIS / SUSPENSION / BRAKES |
|
Brake Mode(Fr./Re) | Disc/Drum |
Brake Performance | 7m/30km/h |
Front Tire | 2.75-18 |
Rear Tire | 100/90-18 |
Tyire Pressure(kpa) | F:225 R:225 |
DIMENSIONS |
|
Dimension (mm) | 2010x780x1100 |
Dry Weight(kg) | 135KGS |
Min.Ground Clearance (mm) | 155mm |
Wheelbase(mm) | 1340mm |
Standard Loading(kg) | 150KGS |
Max.Speed (km/h) | 90km/h |
Seat Height (mm) | 790mm |
Climb(°) | ≥20° |
